| Operating weight | 23,974 kg |
| Standard bucket | 4.2 m³ |
| Maximum gross power | 220 kW (295 hp) @ 1,600 rpm |
| Maximum net power | 199 kW (267 hp) @ 1,600 rpm |
| Rated load | 7,000 kg |
| Total cycle time | 10.3 s |
| Tipping load-full turn | 16,765 kg |
| Bucket breakout force | 203 kN |
| Dump clearance, full height discharge | 3,151 mm |
| Dump reach, full height discharge | 1,309 mm |
| Model | Cummins 6LTAA8.9 |
| Emissions | EPA Tier 2 / EU Stage II |
| Aspiration | Turbocharged ﹠ air-to-air intercooled |
| Length with bucket down | 9,150 mm |
| Width over tires | 2,970 mm |
| Cab height | 3,580 mm |
| Turning radius, outside of tire | 6,625 mm |
| Bucket capacity | 4.2-8.0 m |
| General Purpose | 4.2 m³ |
| Light material | 6.0, 7.0, 8.0 m³ |
| Heavy-rock | 3.5, 4.2 m³ |
